Polaris Refines RZR Line for 2013

Each year, the entire SXS industry waits in great anticipation of what Polaris is going to do with their model-year release. In recent years, there has been no shortage of market-leading vehicles delivered each year by Polaris. The 2013 RZR line sees the most major improvements, across the line, of any of the previous years. Read on to learn the details.

rzr570_le_blackorange_3q_132013 RZR 570

Perhaps the most underestimated vehicle in the RZR family, this model receives a new limited edition model for 2013, “Trail Limited Edition”, which sees major improvements:

  • Electronic Power Steering (EPS)
  • Engine Braking System (EBS)
    • EBS is accomplished with a drive and driven clutch configuration that maintains tension on the CVT drive belt keeping the engine coupled to the drive wheels which slows the vehicle down when going down hills.  In contrast, a non-EBS clutch system allows the engine to decouple from the engine when the throttle is released and then engine RPM returns to idle.
  • Versatrack Turf Mode
    • Turf Mode can be enabled with the switch on the dash at any vehicle speed but there is an electronic control that will not allow the differential to lock or unlock until the wheel speed drops below 15mph.
    • Turf Mode utilizes a solenoid that moves a pin that either allows the rear gearcase to drive just one wheel in a traditional differential mode, or when engaged, locks both the right and left hand wheels together.
    • Upgrading a base model 570 to have turf mode would be cost prohibitive and is not recommended.
  • Glove Box
  • Under hood access panel and dry storage case
  • New black plastic with orange and white graphics
  • Flow-through seatbelt tongue for easy adjustment

The 2013 RZR 570 is available in the following models:

  • Trail Limited Edition
  • Standard Polaris red

pol_570_rzr_le_13


rzr800_bluefire_3q_132013 RZR 800 and RZR 4 800

The vehicle that single-handedly birthed the sport UTV market, the RZR 800 is once again refined on its path to becoming the ultimate all-around sport UTV.

  • Dual-rate shock springs to increase ground clearance and suspension performance
  • Driven clutch that reduces decelaration noise.
    • The back angle of the driven clutch helix has been improved. The new helix angle prevents upshift of the driven clutch during a deceleration that was responsible for the shuffle noise.
  • Engine Braking System (EBS) on all Electronic Power Steering (EPS) units
    • Engine Braking is accomplished with a drive and driven clutch configuration that maintains tension on the CVT drive belt keeping the engine coupled to the drive wheels which slows the vehicle down when going down hills.  In contrast, a non-EBS clutch system allows the engine to decouple from the engine when the throttle is released and then engine RPM returns to idle.
  • Flow-through seatbelt tongue for easy adjustment

For 2013, the RZR 800 is available in the following models:

  • Nuclear Sunset Limited Edition
  • Sunset Red Limited Edition
  • Blue Fire EPS
  • Polaris Pursuit Camo
  • Standard Polaris Red

rzrxp900_indyrd_3q_132013 RZR XP 900 and RZR XP4 900

The undisputed king of sport UTV’s sees major improvements for 2013 that will surely increase its grip on the sport UTV market.

  • Larger 300 lb Rear Lock&Ride® cargo bed with built-in rack extenders and flat bed
  • Flow-through seatbelt tongue for easy adjustment
  • Easier shifting out of park – Three changes were made to the transmission to improve shift effort:
    • Added a bushing to the shift fork to reduce friction.
    • Added a roller on end of the detent pawl to ease movement between gears.
    • Lowered the peaks on the star detent wheel to reduce force needed between gears.
  • Wet sump engine oiling system – Polaris chose the new wet sump system over the previous dry sump system for the following reasons:
    • Removal of the oil reservoir allowed for the removal of the housing and access cover over the oil reservoir in the rear cargo bed. This resulted in a flat cargo bed that makes it much easier for a consumer to load a large cooler or other gear for their day of riding.
    • Wet sump engines are easier to maintain with only one point where the oil must be drained from the oil pan under the engine vs. a dry sump where oil must be drained from both the reservoir and the engine case.
    • Relocating the oil storage location from the higher mounted reservoir to directly under the engine (without changing the elevation of the engine) has a small but positive impact on lowering the center of gravity of the engine.

With the new wet sump system, the overall engine oil capacity does not change. A new engine oil pan has been designed to accommodate the storage of oil below the engine. The engine position does not change within the chassis.

The 2013 RZR XP 900 (2 Seat) is available in the following models:

  • Stealth Black/Evasive Green Limited Edition
  • Orange Madness/Blue EPS Limited Edition
  • Black/White Walker Evans EPS Limited Edition
  • Standard Polaris Red

pol_xp900_we_13_12

2013 Polaris RZR Price List
The prices for the 2013 lineup of Polaris RZR’s and Rangers were announced last night. The full list including the RZR 570, RZR 800, RZR 4 800, RZR XP 900, and RZR XP 4 900 are all listed below. Also included in this lineup are the new limited edition models.

RZR XP 900′s (2 seaters)

  • 2013 Polaris RZR XP 900 EPS Walker Evans – $18,199
  • 2013 Polaris RZR XP 900 EPS Orange Madness/Blue – $17,799
  • 2013 Polaris RZR XP 900 Stealth Black/Evasive Green LE – $16,799
  • 2013 Polaris RZR XP 900 (base) – $15,999

RZR XP 4 900′s (4 seaters)

  • 2013 Polaris RZR XP 4 (4 seater) 900 EPS Black/White/Red – $19,599
  • 2013 Polaris RZR XP 4 (Base) – $17,999

2013 Polaris RZR and Ranger Price List

MODEL # MODEL NAME MSRP*
FULL-SIZE
R13TH76AG RANGER® 800 EFI Sage Green $11,399
R13TH76AR RANGER® 800 EFI Solar Red $11,399
R13TH76AH RANGER® 800 EFI Polaris Pursuit® Camo $12,099
R13TH7EAG RANGER® 800 EPS Sage Green $12,399
R13TH76AZ RANGER® 800 EFI Sunset Red LE $12,099
R13TH76AK RANGER® 800 EFI Black/White Lightning LE $12,099
R13TH7EAZ RANGER® 800 EPS Sunset Red LE $13,099
R13TH7EAK RANGER® 800 EPS Black/White Lighting LE $13,099
R13TH90DG RANGER® DIESEL $12,999
R13UH88AG RANGER XP® 900 Sage Green $12,999
R13UH88AR RANGER XP® 900 Solar Red $12,999
R13UH88AC RANGER XP® 900 Polaris Pursuit® Camo $13,799
R13UH9EAR RANGER XP® 900 EPS Solar Red $13,999
R13UH9EAG RANGER XP® 900 EPS Sage Green $13,999
R13UH88AZ RANGER XP® 900 Sunset Red LE $13,799
R13UH88AO RANGER XP® 900 Orange Madness LE $13,799
R13UH88AQ RANGER XP® 900 Bronze Mist LE $14,399
R13UH9EAZ RANGER XP® 900 EPS Sunset Red LE $14,799
R13UH9EAO RANG
ER XP® 900 EPS Orange Madness LE
$14,799
R13UH9EAB RANGER XP® 900 Browning® LE $15,799
MID-SIZE
R13RH45AG RANGER® 400 Sage Green $8,299
R13RH50AG RANGER® 500 EFI Sage Green $9,299
R13RH50AR RANGER® 500 EFI Solar Red $9,299
R13RH50AH RANGER® 500 EFI Polaris Pursuit® Camo $9,799
R13RH50AM RANGER® 500 EFI Magnetic Metallic LE $9,999
R13RH76AG RANGER® 800 EFI Midsize Sage Green $10,499
R13RH76AH RANGER® 800 EFI Midsize Polaris Pursuit® Camo $10,999
R13RH76AN RANGER® 800 EFI Midsize Nuclear Sunset LE $11,199
R13RC08GA RANGER® EV Board Walk Blue $10,999
R13RC08GH RANGER® EV Polaris Pursuit® Camo $11,499
MULTI-PASSENGER
R13WH50AR RANGER CREW® 500 EFI Solar Red $10,299
R13WH50AG RANGER CREW® 500 EFI Sage Green $10,299
R13WH50AH RANGER CREW® 500 Polaris Pursuit® Camo $10,799
R13WH50AX RANGER CREW® 500 Sandstone Metallic LE $10,999
R13WH76AG RANGER CREW® 800 Sage Green $12,499
R13WH76AR RANGER CREW® 800 Solar Red $12,499
R13WH7EAH RANGER CREW® 800 EPS Polaris Pursuit® Camo $14,199
R13WH7EAI RANGER CREW® 800 EPS Blue Fire LE $13,999
R13WH90DG RANGER CREW® DIESEL $13,999
R13HR76AG RANGER® 6×6 800 Sage Green $12,599
R13HR76AR RANGER® 6×6 800 Solar Red $12,599
RZR
R13VH57AD RZR® 570, Indy Red $9,999
R13VH6EAK RZR® 570 EPS Trail LE $11,999
R13VH76AD RZR® 800, Indy Red $11,499
R13VH76AC RZR® 800 Polaris Pursuit® Camo $12,199
R13VH76AN RZR® 800 Nuclear Sunset LE $12,199
R13VH76AS RZR® 800 Sunset Red LE $12,199
R13VH7EAI RZR® 800 EPS Blue Fire LE $13,299
R13VE76AD RZR® S 800, Indy Red $12,699
R13VE76AI RZR® S 800 Blue Fire/Orange LE $13,999
R13VE76AW RZR® S 800 Orange/White LE $13,999
R13JT87AD RZR® XP 900 EFI, Indy Red $15,999
R13JT87AL RZR® XP 900 Stealth Black/Evasive Green LE $16,799
R13JT9EAK RZR® XP 900 EPS Walker Evans Black/White LE $18,199
R13JT9EAO RZR® XP 900 EPS Orange Madness/Blue LE $17,799
R13XE76AD RZR® 4 800, Indy Red $14,499
R13XE7EAI RZR® 4 800 EPS Blue Fire/Orange LE $15,999
R13XT87AA RZR® XP 4 900, Indy Red $17,999
R13XT9EAK RZR® XP 4 900 EPS Black/White/Red LE $19,599

Prices F.O.B. Roseau – Payable in U.S. Funds
*Price does not include Freight and Set-up
Polaris reserves the right to change specifications, models, or pricing at any time without incurring obligations.

Model Year Summary

In today’s turbulent economy, at a time when many manufacturers are releasing “bold new graphics”, Polaris has once again gambled big by making some major changes (wet sump on the XP, EBS, Turf Mode) to their product line. Based on the track record of recent Polaris vehicles, these changes are sure to help them increase their already impressive market share. It makes me proud to see an American company excel in an industry so heavily influenced by international manufacturers.

We look forward to getting our hands on the new 2013 vehicles.

To learn more about the entire 2013 RZR line, visit http://www.polaris.com/en-us/ATV-RANGER/RANGER-RZR-Side-By-Side-Vehicles/Pages/Overview.aspx.
